Get more from your radar – tracking birds, hazards, and storms from greater distances with HALO® 3000. Benefit from safer navigation and unrivalled ease of use with a range of preset modes, including the all-new Bird+ Mode – giving sportfishing enthusiasts the power to the detect flocks of birds at an impressive 8nm. While advanced Pulse Compression technology ensures superior clarity and precision over both short and long distances.
Features:
- 50W power for longer range (from 6m to up to 72nm) and higher-resolution target detection
- Advanced pulse compression technology with beam sharpening
- Simultaneous Dual Range operation
- Easy operation with Harbour, Offshore, Weather, and Bird modes
- Track up to 50 targets with ZoneTrack
- VelocityTrack Doppler technology for collision avoidance
- Dangerous Target Alerts for radar and AIS targets
- Ready instantly from standby, and in 16-25 seconds from power-on
- Available in 3-, 4- and 6-foot arrays
Specifications:
Physical
- Compass Safe STD. 1.0 m (3.3 ft) Steer 0.5 m 1.6 ft)
- Dimensions W x H x D 324 mm x 429 x 339 mm (12.76" x 16.81" x 13.35
- Weight Kit weight 31.6 kg (69.7 lbs)
Electrical
- Power Consumption max 250 W (peak, 12V) at maximum wind velocity
- Power Consumption typical 45-75 W (average) at zero wind velocity
- Recommended Fuse Rating 25 A for 12 V systems or 15 A for 24 V
- Supply Voltage Radar system input 12 OR 24 V DC into the RI-50; 12 V Systems 10.8 - 15 V DC, 24 V Systems 20 - 31.2 V DC. Pedestal voltage input is 50 V DC nominal generated by RI-50
Environment
- Operating Temperature Range -25°C to +55°C (-13°F - 131°F)
- Shock Vibration IEC60945 Exposed product
- Waterproofrating IPX6
Connectivity
- Ethernet Ports Via RI-50, 1 x 100 Mbit RJ45 Adapter to 5 pin yellow supplied)
- NMEA 2000 Connectivity No NMEA 2000 Connection. Heading and other navication data is sent to the radar over the Ethernet network
Approvals
- Approvals Compliance FCC/IC/RED Type Certification : HALO 3000 SERIES; FCC ID: RAYHALO3000 (Navico Inc.) IC ID: 978B-HALO3000 (Navico Inc.) EU RED: Emissions compliant to SM1541-4 (including -40 dB/dec future design objectives) and EN302-248 V2.1.1
Radar
- Beam width 1.2°+/-10% (-3 dB width) – 0.8° with Beam sharpening mode on: Vertical beam width 25° +/-10 % (-3 dB width)
- Max Range, scale 96 nm
- Max Wind Speed 80 Knots (all antenna sizes)
- Min Range, scale 75 m (300 ft)
- Radar Modes Head Up, North Up
- Radar Technology Pulse Compression
- Rotation speed 16 to 48 rpm depending on operating mode.
- Sart Racon Yes – trigger distance: about 1nm max – weather, seastate, and SART position dependent
Other
- Interface Simrad MFD
- Warranty Period 2 Years
