A high-definition 9-inch display, that’s great for centre consoles and other powerboats. Featuring the new iMX 8 high-performance processor, with superfast response times, this compact package delivers extensive functionality. Enjoy stunning clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and keypad for total control in all conditions. Includes world basemap.
Features
- iMX 8 Integrated six-core processor for superior performance
- 9-inch SolarMAX ™ IPS display with ultra-wide viewing angles; viewable through Polarized sunglasses
- Switch seamlessly between touchscreen and keypad control
- Built in high-performance echosounder with 1kW CHIRP
- Built-in GPS receiver and wireless connectivity
- Control Simrad sonar, radar, autopilot, and other accessories
- Industry-standard connectivity to engines, sound system, and more
- TripIntel™ trip planning and support for automatic routing
- Choose low-profile flush mounting or convenient bracket mounting
- Download the Simrad App and connect with smartphones, tablets, and internet hotspots
- Includes world basemap
Specifications:
- Ethernet Ports: 1 x 5 pin yellow connector x 10/100 Mbit
- NMEA 2000 Connectivity: 1 x NMEA 2000 Micro-C port, 1 LEN
- Weight: 1.41 kg (3.11 lbs.)
- Supply Voltage: 10 - 31.2 V DC
- Update rate: 10 Hz
- Shock Vibration: 100 000 cycles of 20 G
- Screen Brightness: 1200 nits
- Display Resolution: 1280 x 720
- Operating Temperature Range: -15°C to +55°C (5° F to 131° F)
- Internal Storage: 16 GB
- SD Card Storage: 2 MicroSD slots, max. 32GB each. Larger if formatted to NTFS
- Video: 2 x composite (RCA connectors)video inputs. Optional video/ data cable required (P/N 000-00129-001).
- Warranty Period: 2 Years
- Power Consumption max: 21 W
- Waterproofrating: IPX6 and 7
