The NMEA0183 interface provides a bi-directional gateway to a NMEA2000 network. Allowing for easy integration with 3rd party NMEA0183 devices on existing NMEA2000 networks and instrument systems, or for retrofitting NMEA 2000 devices with existing NMEA 0183 networks and systems.
Simple mounting, connectivity and a low profile design allows for ease of installation on any vessel.
Key Features:
- Easy to install with plug ‘n play installation
- Supports NMEA0183 Version 4.1
- Filter NMEA0183 rx/tx sentences and configurable transmit frequency
- Compatible with Lowrance, Simrad and B&G MFD’s and instrument displays
- NMEA2000 Compliant
- Micro-C connectivity
Ideal for retrofitting NMEA2000 devices on existing NMEA0183 networks, this interface allows sailors a simple way to upgrade to newer technology, sensors and devices without replacing a whole system. For existing NMEA networks and systems this also allows user to add NMEA0183 devices to your network and instrument system allowing you to choose the products best suited to your boat and sailing.
Specifications:
IP67 waterproof rating
Supply Voltage: 12V DC (9-18V DC)
Power Consumption Max: 0.66W
Operating Temperature Range: -15°C to +55°C
Weight: 0.1kg
Connectivity:
N2K PG Ns: 127237, 127245, 127250, 127251, 127257, 127258, 128259, 128267, 128275, 129025, 129026, 129033, 129283, 129284, 129539, 129540, 130306, 130310, 130312, 130314, 130577
NMEA 0183 Sentences supported: AAM, APB, BOD, BWC, DBT, DPT, GGA, GLL, GSA, GSV, HDG, HDT, MTW, MWD, MWV, RMA, RMB, RMC, ROT, THS, VBW, VDR, VHW, VLW, VTG, XDR, XTE, ZDA
NMEA 2000 Connectivity: 1x NMEA 20000 Micro-C port, 2 LEN
Part #: 000-15939-001
